Multi-Channel EDAQ Anti-Collision System for CNC Machine, IEPE Sensor, 3ms Emergency Stop

Type:Edge Computing Data Collector
Product name:Multi-Channel EDAQ Anti-Collision System for CNC Machine, IEPE Sensor
Accuracy:Better than 0.5%
Measuring range:30~300000RPM
Interface:LAN
Expansion:RS-485
power supply:DC 24V
IEPE incentive source:4mA /24V
Voltage - Supply-sensor:18VDC~28VDC (current source)
Frequency:1~9,000Hz(±10%), 0.5~12,000Hz(±3dB)
Sensitivity (mV/g):100mv/g (160HZ) (25℃)

Brand:
Xiyuan

Availability:



Inquire Add to Basket

Multi-Channel EDAQ Anti-Collision System for CNC Machine, IEPE Sensor, 3ms Emergency Stop

4.产品运行原理

微信图片_20250506170000

Dynamic input	Number of channels		4
	A/D bit number		24
	Input method		Voltage/IEEE/4-20mA
	Signal input bandwidth	Voltage/4-20mA	DC-50kHz
		IEPE	0.3Hz-50kHz（-3dB）
Slow variable simulation input	Number of channels		4
	A/D bit number		16
	Input method		Voltage/4-20mA
	Signal Input Bandwidth		DC-100Hz

Features	Unit	A26D100	A26F100T01C
Measuring range (peak)	g	±50	±80
Sensitivity (25°C)	mV/g	100	100
Frequency response (1dB)	Hz	1-10,000	1-4,000
Frequency response (3dB)	Hz	0.5 -15,000	0.7-8,000
Mounting resonance frequency	Hz	≥25,000	≥20,000
Housing material		304 stainless steel	304 stainless steel
Protection class		IP65	IP65
